| Maximum Printing Resolution |
600 (horizontal) x 1200 (vertical) dpi |
| Print Head / Ink |
Type: |
Individual Ink Cartridges |
| Number of Nozzles: |
Total 4,352 nozzles |
| Ink Cartridge: |
PGI-2700 (Cyan, Magenta, Yellow, Black)
Optional: PGI-2700XL (Cyan, Magenta, Yellow, Black) |
Print Speed*1
Based on ISO / IEC 24734.
Click here
for summary report
Click here
for Document Print and Copy Speed Measurement Conditions |
Document: Colour:
ESAT / Simplex |
Approx. 15.5ipm |
| Document: Colour: |
Max. 26.5ppm*2 |
Document: B / W:
ESAT / Simplex |
Approx. 24.0ipm |
| Document: B / W: |
Max. 32.5ppm*2 |
Document: Colour:
ESAT / Duplex |
Approx. 9.5ipm |
Document: B / W:
ESAT / Duplex |
Approx. 13.0ipm |
Document: Colour:
FPOT Ready / Simplex |
Approx. 7secs. |
Document: B / W:
FPOT Ready / Simplex |
Approx. 6 secs. |
Document: Colour:
FPOT Sleep / Simplex |
Approx. 12secs. |
Document: B / W:
FPOT Sleep / Simplex |
Approx. 10secs. |
| Printable Width |
Up to 203.2mm (8-inch) |
| |
Bordered Printing: |
Top margin: 3mm, Bottom margin: 5mm, Left / Right margin: each 3.4mm (Letter, Legal: Left: 6.4mm, Right: 6.3mm) |
| Bordered Auto Duplex Printing: |
Top margin: 3mm, Bottom margin: 5mm, Left / Right margin: each 3.4mm (Letter, Legal: Left: 6.4mm, Right: 6.3mm) |
| Recommended Printing Area |
Top Margin: |
45.8mm |
| Bottom Margin: |
36.8mm |
| Paper Size |
A4, A5, B5, Letter, Legal, Oficio, B-Oficio*, M-Oficio, Foolscap, Legal (India), Executive,
4 x 6", 5 x 7", 8 x 10", Envelopes (DL, COM10, C5, Monarch)
Custom size [cassette (upper)]: width 89 - 216.0mm, length 127 - 355.6mm, cassette (lower): width 210 - 216.0mm, length 279.4 - 355.6mm)
*Not supported for Mac |
Paper Handling (Cassette1: Upper)
(Maximum Number) |
Plain Paper |
A4, A5, B5, Letter, Legal = 250 |
| Photo Paper Pro Luster (LU-101) |
A4 = 10 |
| Matte Photo Paper (MP-101) |
4 x 6" = 20, A4 = 10 |
| Photo Paper Plus Glossy II (PP-201) |
4 x 6" = 20, A4 = 10 |
Glossy Photo Paper "Everyday Use" (GP-508)
|
4 x 6" = 20, A4 = 10 |
| High Resolution Paper (HR-101N) |
A4 = 65 |
| Photo Paper Plus Semi-Gloss (SG-201) |
4 x 6" = 20, A4, 8 x 10" = 10 |
| Envelope |
Envelopes (DL, COM10, C5, Monarch) = 10, A4, Letter, Legal = 250 |
Paper Handling (Cassette2: Lower)
(Maximum Number) |
Plain Paper |
| Paper Output |
Approx. 75 pages (A4, Letter, Legal) |
Support Media for
Auto 2-sided Printing |
Type: |
Plain Paper |
| Size: |
A4, Letter |
| Paper Weight |
Cassette1 (Upper): |
Plain Paper: 64-105 g/m2,
Canon specialty paper: max paper weight: approx. 275g/m2
(Photo Paper Plus Glossy II PP-201) |
| Cassette2 (Lower): |
Plain Paper: 64-105 g/m2 |
| Ink End Sensor |
Electrical pulse detect + Dot count |
| Print Head Alignment |
Auto / Manual |
| Scan *3 |
|
| Scanner Type |
Flatbed & ADF |
| Scanning Method |
CIS (Contact Image Sensor) ×2 (2-sided) |
| Duplex Scanning |
Available (Single pass 2-sided scan) |
| Optical Resolution *4 |
1200 x 1200 dpi |
| Selectable Resolution *5 |
25 - 19200 dpi |
| Scanning Bit Depth (Input / Output) |
Grayscale: |
16bit / 8bit |
| Colour: |
48bit / 24bit (RGB each 16bit / 8bit) |
| Scanning Speed *6 *15 |
Document (ADF): Colour:
scESAT30secA / Simplex |
Approx. 16.0ipm |
Document (ADF): B / W:
scESAT30secA / Simplex |
Approx. 19.0ipm |
Document (ADF): Colour:
scESAT30secA / Duplex |
Approx. 23.0ipm |
Document (ADF): B / W:
scESAT30secA / Duplex |
Approx. 23.0ipm |
Document (ADF): Colour:
scEFTP30secF / Simplex |
Approx. 15.0ipm |
Document (ADF): B / W:
scEFTP30secF / Simplex |
Approx. 17.5ipm |
Document (ADF): Colour:
scEFTP30secF / Duplex |
Approx. 21.0ipm |
Document (ADF): B / W:
scEFTP30secF / Duplex |
Approx. 21.5ipm |
| Maximum Document Size |
Flatbed |
A4, Letter (216 x 297mm) |
| ADF |
A4 / Letter / Legal |
| Copy |
|
| Maximum Document Size |
A4, Letter (216 x 297mm)
ADF: A4 / Letter / Legal |
| Compatible Media |
Size: |
A6, A4, A5, B5, Letter, Legal, Oficio, B-Oficio, M-Oficio, Foolscap, Legal (India), Executive, 4 x 6", 5 x 7" |
| Type: |
Plain Paper
Photo Paper Plus Glossy II (PP-201)
Photo Paper Plus semi-Gloss (SG-201)
Glossy Photo Paper "Everyday Use" (GP-508)
Matte Photo Paper (MP-101)
Photo Paper Pro Luster (LU-101)
|
| Image Quality |
2 positions (Standard, High) |
| Density Adjustment |
9 positions, Auto intensity (AE copy) |
Copy Speed *9
Based on ISO / IEC 29183.
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions |
Document: Colour:
sFCOT / Simplex |
Approx. 11secs. |
Document (ADF): Colour:
ESAT / Simplex |
Approx. 11.5ipm |
Document (ADF): B / W:
ESAT / Simplex |
Approx. 22.0ipm |
Document (ADF): Colour:
ESAT / Duplex |
Approx. 6.0ipm |
Document (ADF): B / W:
ESAT / Duplex |
Approx. 10.0ipm |
| Multiple Copy |
Black / Colour: |
max. 99 pages |
| Fax |
|
| Type |
Desktop Transceiver (Super G3 / Color Communication) |
| Applicable Line |
PSTN (Public Switched Telephone Network) |
| Transmission Speed *8 |
Black: |
Approx. 3secs. (33.6kbps) |
| Colour: |
Approx. 1min. (33.6kbps) |
| Fax Resolution |
Black: |
8pels/mm x 3.85lines/mm (Standard)
8pels/mm x 7.7lines/mm (Fine)
300 x 300dpi (Extra Fine) |
| Colour: |
200 x 200dpi |
| Print Size |
A4, Letter, Legal |
| Scanning Width |
208mm (A4), 214mm (Letter) |
| Modem Speed |
maximum 33.6kbps (Automatic fall back) |
| Compression |
Black: |
MH, MR, MMR |
| Colour: |
JPEG |
| Gradation |
Black: |
256 levels |
| Colour: |
24bit Full color (RGB each 8bit) |
| ECM (Error Correction Mode) |
ITU - T T.30 compatible |
| Automatic Dialing |
Coded Speed Dialing |
max. 100 locations |
| Group Dialing |
max. 99 locations |
| Transmission / Reception Memory *9 |
Approx. 250 pages |
| PC Fax |
|
| PC FAX |
Windows: Available, Mac: Available |
| Destination Number |
1 location |
| Black / Colour |
B / W transmission only |
| Network |
|
| Protocol |
SNMP (Standard MIB), TCP / IP |
| Wired LAN |
Network Type: |
IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T) |
| Data Rate: |
10M / 100Mbps (auto switchable) |
| Wireless LAN |
Network Type: |
IEEE802.11n / IEEE802.11g / IEEE802.11b |
| Frequency Band: |
2.4GHz |
| Channel: |
1 - 13 |
| Range: |
indoor 50m (depends on the transmission speed and conditions) |
| Security: |
WEP64 / 128bit, WPA-PSK (TKIP / AES), WPA2-PSK (TKIP / AES) |
| Direct connection (Wireless LAN) |
Available |
| Printing Solutions |
|
| Apple AirPrint |
Available |
| Layout |
1-up (bordered only) |
Letter, A4, 4 x 6", 5 x 7", 8 x 10",
A5, B5, Legal,
A6, Oficio, M-Oficio, Foolscap, Legal (India), Executive,
Envelopes (DL, COM10, C5, Monarch)
Custom size [cassette (upper)]: width 89 - 216.0mm, length 127 - 355.6mm, cassette (lower): width 210 - 216.0mm, length 279.4 - 355.6mm) |
| Print Quality *12 |
Standard / High |
| Microsoft Mobile Print |
Available |
| Layout |
1-up (bordered only) |
Letter, A4, 4 x 6", 5 x 7", 8 x 10",
A5, B5, Legal, Envelopes (DL, COM10) |
| Print Quality *12 |
Standard / High |
| Mopria |
Available |
| Google Cloud Print |
Available |
Canon Print Service Plugin
(for Android OS)
|
Available |
| PIXMA / MAXIFY Cloud Link |
from smartphone or tablet: |
Available |
| from printer: |
Available |
Canon PRINT Inkjet / SELPHY
(for iOS / for Android)
Canon Easy-PhotoPrint
(for Windows RT) |
Available |
| Layout |
1-up (bordered only) |
Letter, A4, 4 x 6", 5 x 7", 8 x 10",
A5, B5, Legal,
A6, Oficio, B-Oficio, M-Oficio, Foolscap, Legal (India), Executive |
| Print Quality |
Fixed |
System Requirements
(Please visit www.canon-asia.com to check OS compatibility and to download the latest driver updates.) |
Windows: |
Windows 10, Windows 8, Windows 7 SP1, Windows Vista SP2 |
| Macintosh: |
Mac OS X v10.8.5 and later |
| General Specifications |
|
|
| Operation Panel |
Display: |
LCD (3.5-inch / 8.8cm TFT color / Touch) |
| Language: |
33 Languages Selectable: Japanese / English (mm & inch) / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovak / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Croatian / Thai / Vietnamese |
| ADF |
Paper Handling (Plain Paper 17 lb. Bond) |
A4 / Letter = 50, Legal = 10, Others = 1 |
| Auto 2-sided |
Available (Single pass 2-sided scan) |
| Interface |
USB A Port |
USB flash memory |
| USB B Port |
USB 2.0 High Speed |
| USB Flash Memory |
File Format *16 |
JPEG and TIFF (Exif-compliant) taken by DCF (Ver.1.0 / 2.0) compliant digital cameras. (Exif ver2.2 / 2.21 / 2.3 compliant) |
| Operating Environment *12 |
Temperature: 5 - 35°C
Humidity: 10 - 90% RH (no dew condensation) |
| Recommended Environment *13 |
Temperature: 15 -30°C ?
Humidity: 10 - 80% RH (no dew condensation) |
| Storage Environment |
Temperature: 0 - 40°C ?
Humidity: 5 - 95% RH (no dew condensation) |
| Quiet mode |
Available |
| Acoustic Noise (PC Print) |
Document (A4, B/W, Default) *10 |
Approx. 56dB(A) |
| Power |
AC 100-240V 50/60Hz |
| Power Consumption |
Standby (scanning lamp is off)
USB connection to PC
|
Approx. 0.9W |
| OFF |
Approx. 0.3W |
Copying *11
(USB connection to PC):
|
Approx. 27W |
Typical Electricity Consumption
(TEC) *14 |
Approx. 0.2kWh |
| Environment |
Regulation: |
RoHS (EU, China)*, WEEE (EU)*
*To be fixed |
| Eco-Label: |
Energy Star*
*To be fixed |
| Duty Cycle |
up to 30,000 pages/month |
| Dimension (W x D x H) |
Factory configuration |
Approx. 463 x 394 x 351mm |
| Paper installed (A4 / LTR) |
Approx. 463 x 459 x 351mm |
| Output / ADF trays extended |
Approx. 463 x 607 x 389mm |
| Weight |
Approx. 12.9kg |
