PRINT |
Print Head/Ink |
|
Type |
Permanent (Replaceable) |
Number of Nozzles |
Total 1,792 nozzles |
Ink Bottles |
GI-70 (Pigment Black / Cyan / Magenta / Yellow) |
Maximum Printing Resolution |
4800 (horizontal)*1 x 1200 (vertical) dpi |
Print Speed*2 |
Based on ISO/IEC 24734 Click here for Summary Report Click here for Document Print and Copy Speed Measurement Conditions |
Document (ESAT/Simplex) |
Approx. 13.0ipm (black) / 6.8ipm (colour) |
Document (ESAT/Duplex) |
Approx. 4.8ipm (black) / 2.8ipm (colour) |
Document (FPOT Ready / Simplex) |
Approx. 9sec (black) / 14sec (colour) |
Photo (4x6") (PP-201/Borderless) |
Approx. 37sec. |
Printable Width |
Up to 203.2mm (8" Borderless: Up to 216mm (8.5") |
Printable Area |
|
Borderless Printing*3 |
Top/Bottom/Right/Left margin: Each 0 mm |
Bordered Printing |
#10 Envelope/DL Envelope: |
Top 8 mm / Bottom 12.7 mm / Right 5.6 mm / Left 5.6 mm |
127x127 mm: |
Top 6 mm / Bottom 6 mm / Right 6 mm / Left 6 mm |
89x89 mm / 4x4": |
Top 5 mm / Bottom 5 mm / Right 5 mm / Left 5 mm |
LTR / LGL: |
Top 3 mm / Bottom 5 mm / Right 6.3 mm / Left 6.4 mm |
Others: |
Top 3 mm / Bottom 5 mm / Right 3.4 mm / Left 3.4 mm |
Bordered Auto 2-Sided Printing |
Top / Bottom margin: 5 mm, Left / Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm) |
Support Media |
|
Rear Tray |
Plain Paper (64-105g/m²) Photo Paper Pro Platinum (PT-101) Photo Paper Pro Luster (LU-101) Photo Paper Plus Glossy II (PP-201/PP-208) Matte Photo Paper (MP-101) Glossy Photo Paper "Everyday Use" (GP-508) High Resolution Paper (HR-101N) Photo Paper Plus Semi-Gloss (SG-201) Photo Stickers (PS-108/PS-208/PS-808) Removable Photo Stickers (PS-308R) Magnetic Photo Paper (PS-508) Envelope |
Cassette |
Plain Paper (64-105g/m²) |
Paper Size |
|
Rear Tray |
A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91x55 mm)
[Custom size] width 55 - 215.9 mm, length 89 - 676 mm
|
Cassette |
A4, A5, B5, LTR
[Custom size] width 148.0 - 215.9 mm, length 210 - 297 mm
|
Paper Size (Borderless)*4 |
A4, LTR, 4x6", 5x7", 7x10", 8x10", Square (5x5",4x4",89x89 mm), Card Size (91x55 mm) |
Paper Handling (Maximum Number) |
|
Rear Tray |
Plain Paper (A4, 64g/m²) = 100 High Resolution Paper (HR-101N) = 80 Photo Paper: 4x6" = 20 |
Cassette |
Plain Paper (A4, 64/m²) = 250 |
Support Media for Auto 2-sided printing |
|
Type |
Plain Paper |
Size |
A4, A5, B5, LTR |
Paper Weight |
|
Rear Tray |
Plain Paper: 64-105g/m² Canon paper: Max paper weight: Approx. 300g/m² (Photo Paper Pro Platinum PT-101) |
Cassette |
Plain Paper: 64-105g/m² |
Ink End Sensor |
Electrode type and dot count type combined |
Print Head Alignment |
Auto/Manual |
NETWORK |
Protocol |
TCP/IP, SNMP |
Wired LAN |
|
Network Type |
IEEE802.3u (100BASE-TX) / IEEE802.3 (10BASE-T) |
Data Rate |
10M/100Mbps (Auto switchable) |
Wireless |
|
Network Type |
IEEE802.11n / IEEE802.11g / IEEE802.11b |
Frequency Band |
2.4GHz |
Channel*4 |
1-13 |
Range |
Indoor 50m (Depends on the transmission speed and conditions) |
Security |
WEP64/128bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
Direct Connection (Wireless LAN) |
Available |
PRINT SOLUTIONS |
AirPrint |
Available |
Windows 10 Mobile |
Available |
Mopria |
Available |
Google Cloud Print for Android |
Available |
Canon Print Service for Android |
Available |
PIXMA Cloud Link (from smartphone/tablet |
Available |
Message in Print (for iOS/for Android) |
Available |
Easy Photo-Print Editor (for iOS/for Android) |
Available |
Canon PRINT Inkjet/SELPHY (for iOS/for Android) |
Available |
System Requirements*5 |
Windows 10 / 8.1 / 7 SP1 (Operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)
Mac OS X 10.10.5 ~ OX 10.11 Mac OS v10.12 ~ 10.14
|
GENERAL SPECIFICATIONS |
Display |
2-Line LCD |
Language |
32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese |
Interface |
Hi-Speed USB 2.0 |
PictBridge (Wireless / Wired LAN |
Available |
Operating Environment*6 |
|
Temperature |
5 - 35°C |
Humidity |
10 - 90% RH (no dew condensation) |
Recommended Environment*7 |
|
Temperature |
15 - 30°C |
Humidity |
10 - 80% RH (no dew condensation) |
Storage Environment |
|
Temperature |
0 - 40°C |
Humidity |
5 - 95% RH (no dew condensation) |
Quiet Mode |
Available |
Acoustic Noise (PC Print) |
|
Plain Paper (A4, B/W)*8 |
Approx. 52.0dB(A) |
Power |
AC 100-240V, 50/60Hz |
Power Consumption |
|
OFF |
Approx. 0.3 W |
Standby (scanning lamp is off) USB connection to PC |
Approx. 0.8W |
Standby (all ports connected, scanning lamp is off) [EU only - for ErP Lot 26 regulation] |
Approx. 1.6W |
Time to enter Standby mode [EU only - for ErP Lot 26 regulation] |
Approx. 1min 10sec. |
Printing*9 USB connection to PC |
Approx. 21W |
Typical Electricity Consumption (TEC)*10 |
0.2 kWh |
Environment |
|
Regulation |
RoHS (EU, China), WEEE (EU) |
Duty Cycle |
Up to 5,000 pages/month |
Dimension (WxDxH) |
|
Factory Configuration |
Approx. 403 x 369 x 166 mm |
Output/ADF trays extended |
Approx. 403 x 695 x 356 mm |
Weight |
Approx. 6.5kg |
PAGE YIELD |
Plain Paper (A4 pages) (ISO/IEC 24712 test file)*11 |
Standard: GI-70 PGBK: 6,000 GI-70 C/M/Y: 7,700
Economy>*13: GI-70 PGBK: 8,300 GI-70 C/M/Y: 7,700
|
Photo Paper (PP-201, 4x6") (ISO/IEC 29103 test file)*12 |
Standard: GI-70 PGBK: NA GI-70 C/M/Y: 2,200 |
